詳細介紹
1、電源參數,Power supply parameter
|
|
置入方式posting Mode |
外置恒流驅動 |
|
|
輸入電壓Input Voltage |
AC85V～265V |
|
|
電源頻率Freqency Range |
50Hz～60Hz |
|
|
最大輸入功率Max Power |
205W |
|
|
總諧波失真Total Harmonic Distortion |
≤ 8 % |
|
|
功率因數Power Factor |
＞0.95 |
|
|
電源效率Power Efficiency |
＞91 % |
|
|
輸出模式Outputmode |
CC恒流模式 |
|
|
輸出電壓Output Voltage |
DC 42-45V |
|
|
輸出電流Output Current |
4.2A |
|
|
電源尺寸Power size |
210mm*79mm*45mm |
|
|
認證，證書Certificate |
CE |
|
|
壽命Life |
30000 H |
2、燈具技術參數
|
|
LED工作電壓Working Voltage |
DC45～48V |
||
|
|
LED數量Led |
90 pcs |
||
|
|
LED功耗Led Consumption |
182 W |
||
|
|
系統總功耗System Consumption |
202 W |
||
|
|
LED發光效率Led Luminous Efficiency |
90Lm /W |
||
|
|
LED燈具初始光通量Led Initial Flux |
18000 Lm |
||
|
|
燈具效率lamp’s Efficiency |
＞93% |
||
|
|
平均照度 Average Illuminance |
6M |
1050Lux |
|
|
|
8M |
850Lux |
||
|
|
10M |
550Lux |
||
|
|
光斑面積 Illuminance Area |
6M |
直徑6M |
|
|
|
8M |
直徑8M |
||
|
|
10M |
直徑10M |
||
|
|
照度均勻度Illuminance Uniformity |
＞0.7 |
||
|
|
相關色溫Color Temperature |
詳見上述LED參數表 |
||
|
|
顯色指數Color Rendering Index |
Ra＞75 |
||
|
|
配光曲線Light Distribution |
對稱式/圓形光斑 |
||
|
|
配光方式Light Design |
LED+透鏡二次配光 |
||
|
|
LED結點溫升Junction Temperature |
≤85℃ |
||
|
|
工作環境溫度Working Temperature |
-40℃～+55℃ |
||
|
|
儲存環境溫度Storage Temperature |
-25℃～+65℃（25℃最佳） |
||
|
|
防護等級IP Grade |
IP65 |
||
|
|
凈重Net weight |
6.8Kg |
||
|
|
光源使用壽命Working Life-span |
30000H |
||
|
|
電源線Power line |
1mm2三芯線 |
||
|
|
電源線連接Connect Wire |
棕Brown |
L火線 |
|
|
|
藍Blue |
N零線 |
||
|
|
黃綠Yellow/Green |
G地線 |
||
|
|
燈頭外殼顏色（The color of the lamp shell） |
白色 |
||
